Pylontech US3000

The Pylontech US3000 battery module is a reliable and efficient solution for energy storage in residential and commercial applications. With a capacity of 3.55 kWh, this battery offers an excellent balance between performance, durability and flexibility.

Construction of the Pylontech US3000:

✔ 1x 3.55 kWh battery module

✔ Compatible with various 48V inverters

✔ Possibility of parallel connection for larger capacity

Technical specifications:

• Nominal voltage: 48V DC

• Nominal capacity: 3552 Wh

• Usable capacity: 3374 Wh

• Recommended charge and discharge current: 37A

• Maximum continuous current: 37A

• Communication: RS485, CAN

• Protection class: IP20

• Dimensions: 442 x 420 x 132 mm

• Weight: 32 kg

• Lifespan: >6000 cycles at 25°C

• Mounting: Rack-mounted, suitable for multiple parallel units

Datasheet Download
