Dyness PowerBrick Plus 16.07 kWh Home Battery

The Dyness PowerBrick Plus is a LiFePO4 home battery with a nominal energy content of 16.07 kWh (usable 15.27 kWh) and a nominal capacity of 314 Ah at 51.2 V. The battery supports a maximum charge and discharge current of 200 A (10.24 kW) and is expandable up to 50 units in parallel for a total storage capacity of up to 803 kWh. The system features a built-in aerosol fire extinguisher, active self-heating system, caster wheels, and an IP65 protection rating for indoor and outdoor installations.

• LiFePO4 cell chemistry: 16.07 kWh nominal energy, 15.27 kWh usable, 95% DOD.
• High power: max. charge and discharge current 200 A with 10.24 kW peak power.
• Long lifespan: ≥ 8000 charge cycles at 95% DOD including a 10-year warranty.
• Integrated safety: aerosol fire extinguisher and active self-heating system.
• Flexible scalability: expandable from 16 kWh up to a maximum of 803 kWh.

Technical validation & configuration

Technical explanation for installers

The Dyness PowerBrick Plus is a low-voltage LiFePO4 battery module with a nominal voltage of 51.2 V and an operational voltage range of 44.8–57.6 V. The integrated BMS handles cell balancing, temperature protection, and communication via CAN or RS485. The system supports up to 50 units connected in parallel and is compatible with selected low-voltage inverters from brands including GoodWe, Solis, Growatt, SMA, Victron, SOFAR, SolaX Power, Deye, Luxpower, and Voltronic Power. The active self-heating system allows charging down to –20 °C. Installation must be performed exclusively by certified electrical installers in accordance with national standards.
