BYD Battery-Box HVS+ 10.2 (10.24kWh) | High Voltage Storage System
Couldn't load pickup availability
High Voltage Storage for Maximum Efficiency and Independence
The BYD Battery-Box HVS+ 10.2 represents the pinnacle of high-voltage residential energy storage. Offering a substantial 10.24 kWh capacity and operating at a nominal 409.6V, this system ensures superior efficiency by minimizing conversion losses. Its patented modular plug design allows for easy, wiring-free installation. Utilizing Cobalt-free Lithium Iron Phosphate (LFP) technology, it provides unmatched safety and longevity. Compatible with leading inverter brands like Solis and GoodWe, this battery is the perfect solution for maximizing self-consumption, providing backup power, and achieving energy independence.
- High Voltage Efficiency: 409.6V nominal voltage for high-power charging/discharging capabilities.
- Modular & Scalable: Easily expandable by adding HVS+ modules (up to 5 per tower) anytime.
- IP55 Rated: Engineered for durability, suitable for both indoor and outdoor installation.
- Certified Safety: Meets VDE2510-50 and IEC62619 standards with cobalt-free LFP chemistry.
| Specification | Value |
|---|---|
| Model (MPN) | BYD-HVS-PLUS-10.2 |
| Usable Capacity | 10.24 kWh |
| Technology | Lithium Iron Phosphate (LFP) - Cobalt Free |
| Nominal Voltage | 409.6 V |
| Dimensions (H x W x D) | 1227 x 610 x 282 mm |
| Weight | 168.1 kg |
| IP Rating | IP55 (Indoor/Outdoor) |
| Warranty | 10 Years |
What is included in the package?
The BYD Battery-Box HVS+ 10.2 set comes with everything needed for the battery tower structure:
- 1x BCU (Battery Control Unit) including Base.
- 4x HVS+ Battery Modules (2.56 kWh each).
- 2x Power cable connectors for BCU.
- 1x Terminal resistor.
- 2x Wall hangers (Hanger 1 & Hanger 2) for stability.
- Mounting hardware (screws, anchors).
- Documentation (Quick Start Guide).
- Note: DC power cables to the inverter are not included and should be sourced locally (6mm² or 10mm²).
Which inverters are compatible?
The HVS+ series features extensive compatibility with major high-voltage hybrid inverters. For the best experience, we recommend:
- Solis: S6-EH3P Series.
- GoodWe: ET Series (15-30kW) & ET G2.
- Also compatible with Fronius (Gen24 Plus), Kostal (Plenticore), and KACO.
Please always verify the specific model and firmware requirements in the "Compatible Inverter List" linked above.
Is the system expandable?
Yes, the HVS+ system is highly modular. You can expand this 10.2 system by stacking one additional HVS+ module to reach 12.8 kWh in a single tower. For even larger capacity, up to 3 towers can be connected in parallel, reaching a maximum of 38.4 kWh. Expansion allows you to start small and grow your storage as your energy needs increase.
What about safety and certification?
The BYD Battery-Box HVS+ uses Cobalt-free Lithium Iron Phosphate (LFP) chemistry, known for its high thermal stability and safety. The system is IP55 rated for protection against dust and water jets. It holds major international certifications including VDE2510-50, IEC62619, CE, and UN38.3, ensuring it meets the highest global safety standards.
Can I use this for Off-Grid applications?
Yes, the BYD HVS+ is capable of Off-Grid operation, provided it is paired with a compatible inverter that supports Off-Grid functionality (such as select models from GoodWe or Solis). This makes it an excellent choice for remote locations or ensuring power supply during grid outages.
View our full range of storage solutions in the BYD Collection.
