GoodWe GW8000-ET-20 is a powerful three-phase hybrid inverter for HV batteries, with 8 kW nominal power and extensive back-up functionality.
Key Features
- Nominal AC power: 8000 W (8000 VA)
- Backup apparent power: 8000 VA (peak 16,000 VA / 60 s)
- Maximum efficiency: 98.0% • European efficiency: 97.2%
- 2 MPPTs • max. PV input: 12,800 W • max. voltage 1000 V
- Battery range: 150–720 V • charge/discharge up to 12,000 W / 8800 W
- Communication: RS485 & CAN, Wi-Fi, LAN, Bluetooth
- IP66, natural convection, noise level <30 dB
Technical data
- Output voltage: 400/380 V, 3L/N/PE • 50/60 Hz
- Max. AC current to mains: 11.6 A • from mains: 21.0 A
- Dimensions: 496 × 460 × 221 mm • weight: 23 kg
- Protection: Surge protection type II (DC/AC), DC switch, RCMU, AFCI optional
