GoodWe GW8000-ET-20 Hybrid

Price excluding VAT

Regular price €1.179,00 EUR
Regular price Sale price €1.179,00 EUR

Register as an installer to view your net prices. Already have an account? Log in here.

Shipping calculated at checkout.

GoodWe GW8000-ET-20 is a powerful three-phase hybrid inverter for HV batteries, with 8 kW nominal power and extensive back-up functionality.

Key Features

  • Nominal AC power: 8000 W (8000 VA)
  • Backup apparent power: 8000 VA (peak 16,000 VA / 60 s)
  • Maximum efficiency: 98.0% • European efficiency: 97.2%
  • 2 MPPTs • max. PV input: 12,800 W • max. voltage 1000 V
  • Battery range: 150–720 V • charge/discharge up to 12,000 W / 8800 W
  • Communication: RS485 & CAN, Wi-Fi, LAN, Bluetooth
  • IP66, natural convection, noise level <30 dB

Technical data

  • Output voltage: 400/380 V, 3L/N/PE • 50/60 Hz
  • Max. AC current to mains: 11.6 A • from mains: 21.0 A
  • Dimensions: 496 × 460 × 221 mm • weight: 23 kg
  • Protection: Surge protection type II (DC/AC), DC switch, RCMU, AFCI optional



Datasheet download
