Pylontech Force H3 25.6kWh Home Battery (512V System)

€5.472,83 incl. 21% VAT
Shipping calculated at checkout.
In Stock
Freight prepaid delivery (NL/BE) from €5,000 order value
Delivery within 3–8 business days (EU)
Direct technical support
More than 20 years of hands-on experience in PV & energy storage
Net discount conditions for registered partners
Professional access
  • Generic
  • Apple Pay
  • Bancontact
  • Google Pay
  • iDEAL
  • Klarna
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Visa

The Pylontech Force H3 25.6kWh is a powerhouse energy storage solution designed for large residential and light commercial applications. This complete set stacks five high-capacity FH10050 modules into a single, vertical unit. Operating at a nominal 512V, this high-voltage system ensures superior efficiency, reduced transmission losses, and rapid charging capabilities.

  • Massive Storage: 25.6 kWh total capacity in one tower (5x 5.12kWh modules).
  • High Voltage: 512V system voltage for optimal inverter performance.
  • Seamless Design: Cable-free internal connections for a clean, professional look.
  • Safety First: Premium LFP technology with IP55 protection rating.

High-Capacity Storage Made Simple

The Force H3 series combines industrial-grade performance with consumer-friendly design. The "stackable" installation method eliminates the need for messy external wiring between modules, reducing installation time and complexity. With over 24kWh of usable energy, this system provides substantial backup power and maximizes self-consumption for solar households.

Weight Warning: Please be aware of the component weights for installation planning.
  • Per Battery Module (FH10050): 39 kg
  • BMS + Base: 14 kg
The total tower weight is approximately 209 kg. Ensure the installation floor is level and capable of supporting this load.
Feature Value
Brand & Model Pylontech Force H3 (25.6kWh Set)
Configuration 5x FH10050 Modules + 1x BMS
Nominal Voltage 512 V (DC)
Total Capacity 25.60 kWh
Dimensions (WxDxH) 540 x 350 x 1210 mm
Total Weight +/- 209 kg
Download Datasheet Download Manual
Can I expand this system further?

Yes, the Force H3 tower can accommodate up to 7 modules in total. Since this set uses 5 modules, you can add 2 more modules later to reach a maximum of 35.84kWh per tower.

How is the system installed?

Installation is straightforward due to the modular design. You place the base, stack the battery modules one by one, and secure them. The BMS unit is placed on top. Internal connectors handle power and data, so no external DC cables are needed between the modules.

Is it suitable for outdoor use?

The system is rated IP55 (dust and water jet resistant). While it can be installed outdoors in a sheltered location, we recommend indoor installation or a protective enclosure to ensure optimal performance and longevity.
