Pylontech Force H3 BMS & Base Kit (Control Unit)

€544,50 incl. 21% VAT
Shipping calculated at checkout.
In Stock
Freight prepaid delivery (NL/BE) from €5,000 order value
Delivery within 3–7 business days (NL/BE)
Direct technical support
More than 20 years of hands-on experience in PV & energy storage
Net discount conditions for registered partners
Professional access
  • Generic
  • Apple Pay
  • Bancontact
  • Google Pay
  • iDEAL Wero
  • Klarna
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Visa

The Pylontech Force H3 BMS & Base Kit serves as the intelligent core and solid foundation of your Force H3 high-voltage energy storage system. This kit includes the Battery Management System (BMS) control unit, which sits atop the tower, and the robust base plate upon which the battery modules are stacked. These components are critical for the operation, safety, and stability of your energy storage setup.

  • The Brain (BMS): Actively manages cell balancing, safety protection, and inverter communication.
  • The Foundation (Base): Ensures a stable, level installation and proper ground clearance.
  • High Voltage Control: Supports system voltages from 204V up to 716V.
  • Seamless Integration: Designed for the Force H3 "stackable" system without external cabling.

Essential Components for Force H3 Towers

The Pylontech Force H3 system is renowned for its modular, easy-to-install design. Installation starts with the Base, providing a secure footprint. After stacking your battery modules (sold separately), the BMS Unit is placed on top to complete the circuit. This controller continuously monitors voltage, current, and temperature, ensuring your system operates efficiently and safely for years to come.

Note: This product includes only the BMS Controller and the Base Plate. To achieve a functional system, you require a minimum of 2 and a maximum of 7 Pylontech FH10050 battery modules.
Feature Value
Brand & Model Pylontech Force H3 (BMS + Base)
Compatibility Pylontech FH10050 Modules
System Voltage Range 204.8 V ~ 716.8 V
Base Dimensions (WxDxH) 540 x 350 x 40 mm
Communication CANBUS / Modbus RTU
IP Rating IP55 (Indoor & Outdoor)
Download Datasheet Download Manual
What does the BMS unit do?

The BMS (Battery Management System) acts as the system's brain. It manages charging and discharging, protects against over-voltage/current/temperature, and communicates the battery's status to your hybrid inverter.

How many modules fit on one base?

For the Force H3 series, a single base can support a stack of minimum 2 and maximum 7 FH10050 battery modules. The BMS unit is always placed on top of the final module.

Is this suitable for outdoor use?

Yes, the components are rated IP55, meaning they are protected against dust and water jets. However, installation under a shelter or in a garage is recommended to protect against direct sunlight and extreme weather.

View compatible battery modules in our Pylontech Collection.
