Pylontech H3X Hybrid Inverter 5kW (Single Phase)

€1.410,86 incl. 21% VAT
Shipping calculated at checkout.
In Stock
Freight prepaid delivery (NL/BE) from €5,000 order value
Delivery within 3–7 business days (NL/BE)
Direct technical support
More than 20 years of hands-on experience in PV & energy storage
Net discount conditions for registered partners
Professional access
  • Generic
  • Apple Pay
  • Bancontact
  • Google Pay
  • iDEAL Wero
  • Klarna
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Visa

The Pylontech Force H3X 5kW (FH3X5K-HY-1P) is an integrated single-phase hybrid energy platform in which Power Controller, system control, battery communication and EMS functionality are brought together within one closed system architecture. This Power Controller unit forms the central control platform of the Force H3X configuration, delivering controlled AC output, high PV processing capacity and ultra-fast backup functionality within a robust residential energy system.

Note: This product includes the Power Controller (Box 1) only. Functional operation requires compatible Pylontech Force H3 Battery Modules (FH10050).
  • Closed System Architecture: Full integration of power control, battery communication and energy management within one platform.
  • UPS-Level Back-up: Automatic transition to island mode in <10 ms.
  • High PV Processing Capacity: Supports up to 9.6 kW PV input via two independent MPPT trackers at 5.0 kW AC nominal output.
  • Advanced DC Protection: Built-in AFCI 2.0 (Arc Fault Circuit Interrupter) with active arc fault detection in accordance with international safety standards.
  • Modular Battery Platform: Engineered exclusively for Force H3 Battery Modules (FH10050).

5kW Hybrid Output with 9.6kW PV Processing Capacity

The Force H3X 5kW supports a maximum PV input of 9.6 kW across two independent MPPT trackers. This configuration enables controlled oversizing to optimise annual yield and winter performance. The integrated EMS regulates bidirectional energy flows based on real-time grid measurement, consumption profile and battery state, ensuring a stable and efficient energy balance.

With a nominal AC output of 5.0 kW (single phase) and a charge/discharge current of up to 50A, this Power Controller is suited for households with elevated simultaneous power demand. The mechanical stack architecture eliminates complex external wiring and reduces installation risks. With an IP55-rated enclosure and C5M corrosion protection, the system is suitable for technical rooms, garages and residential installations with elevated durability requirements.

Feature Value
Brand & Model Pylontech Force H3X (FH3X5K-HY-1P)
Nominal AC Output 5.0 kW (Single Phase)
Maximum PV Input 9.6 kW (2 MPPT)
Max Charge / Discharge Current 50A / 50A
MPPT Voltage Range 80 – 550 V
Back-up Switching Time <10 ms
Communication Bluetooth, WiFi and PylontechPro App
Protection Class IP55 / C5M Corrosion Protection
Warranty 10 years (after registration)
Certifications CE, VDE-AR-N 4105

Note: Battery certifications apply to the connected Pylontech Force H3 (FH10050) battery modules.

Datasheet Download Manual Download PylontechPro App Manual
What is included in Box 1 (Power Controller)?

The delivery of the Power Controller (Box 1) includes all essential components for installation:

  • 1x Power Controller Unit
  • 1x Base Stand
  • Anti-toppling and metal mounting brackets
  • Multi-function terminal & CT clamp
  • AC Grid & AC Back-up connectors
  • PV connection terminals (positive/negative)
  • Communication cables
  • Mounting hardware and documentation
Which batteries are compatible with the Force H3X?

The Force H3X is developed as a closed ecosystem and operates exclusively with Pylontech Force H3 (FH10050) battery modules. Between 1 and 4 modules can be stacked per tower, resulting in a capacity of 5.12 kWh to 20.48 kWh.

Is the system prepared for changing grid structures?

Yes. Thanks to integrated grid measurement, fast response and EMS regulation, the Force H3X supports maximum self-consumption, controlled grid interaction and preparation for future changes in grid regulations and feed-in tariff structures.

What safety mechanisms are integrated in the Power Controller (Box 1)?

The Power Controller (Box 1) features IP55 protection, C5M corrosion resistance and integrated AFCI 2.0 technology for active detection and interruption of DC arc faults. In the event of abnormal electrical conditions, the system automatically disconnects to minimise risk.

The FH3X is visible via Bluetooth but does not appear in the PylontechPro app. What can I do?

If your phone detects the FH3X via Bluetooth but the device does not appear in the PylontechPro app, please check the following steps:

  1. Do not pair the FH3X via your phone's Bluetooth settings. The initial connection must always be made from within the PylontechPro app. Manually pairing the device via Android or iOS Bluetooth settings first can disrupt communication with the app.
  2. Remove any existing Bluetooth pairing. Have you already paired the FH3X via your phone's Bluetooth settings? Remove this connection via 'Forget' or 'Unpair' and try again from within the PylontechPro app.
  3. Check app permissions. Ensure the PylontechPro app has permission to search for Bluetooth devices. Depending on your Android version, the following permissions may be required:
    • Bluetooth / Nearby Devices
    • Location (required for Bluetooth scanning on some Android versions)
  4. Restart Bluetooth and the app. Turn Bluetooth off and back on. Then fully close the PylontechPro app (do not just minimise it) and reopen it.
  5. Search for the device exclusively via PylontechPro. Open the PylontechPro app and allow the app itself to search for the FH3X for Local Configuration. Do not use your phone's Bluetooth settings for this.
  6. Try a different device. If the FH3X still does not appear, test the connection with a second smartphone (preferably a different Android device or an iPhone) to rule out a device- or software-related issue.

For additional configuration steps, refer to the PylontechPro App Manual (PDF).

Explore all system configurations in our Pylontech Storage Collection or combine directly with the required Force H3 FH10050 Battery Modules.
