Pylontech US5000 Stacking Brackets | Set of 2 | Max 3 High
Couldn't load pickup availability
The Pylontech US5000 Stacking Brackets are essential for deploying energy storage systems where cabinet space is unavailable or unnecessary. Engineered specifically for the US5000 chassis, these brackets utilize the battery's corner location holes to lock modules vertically. This creates a rigid, stable tower that ensures proper airflow and cable management while eliminating the cost of a 19-inch rack enclosure.
- Cabinet-Free Install: Reduces footprint and installation costs.
- Max 3 Units: Officially rated for stacks of up to 3 batteries.
- Interlocking Design: Connects lockers for enhanced structural integrity.
- Ventilation Gap: Maintains optimal spacing for thermal regulation.
Reliable Vertical Expansion
Stability is paramount when stacking heavy LFP modules. These brackets engage with the dedicated mounting points on the US5000, preventing any lateral movement. This secure fit is critical for protecting the terminal connections and ensuring long-term safety. The design officially supports a vertical stack of up to 3 modules, allowing for a flexible capacity of 14.4 kWh in a single footprint.
| Feature | Value |
|---|---|
| Brand & Model | Pylontech US5000 Bracket Kit |
| Kit Contents | 2x Bracket (Front/Back) |
| Mounting Type | Vertical Stacking |
| Max Stack Height | 3 Modules |
| Compatibility | Pylontech US5000 Only |
How many bracket sets do I need?
You need 1 set of brackets per battery module. For a 3-module stack, you require 3 sets to ensure the base and inter-module connections are secure.
Can I use these for US2000 or US3000 models?
No, the US5000 has specific dimensions. Pylontech manufactures different brackets for the US2000 and US3000 series. Please verify your battery model before ordering.
Is floor mounting safe?
Yes, provided the floor is level and capable of supporting the weight. The brackets ensure the modules remain aligned and stable, replicating the security of a rack system.
