• FlexHome-BATT-H
  • FlexHome-15kWh-H
1 2

Solis FlexHome-BAT5kWh-H home battery 5kWh module

€1.018,82 incl. 21% VAT
Shipping calculated at checkout.
Out of stock
Freight prepaid delivery (NL/BE) from €5,000 order value
Delivery within 3–7 business days (NL/BE)
Direct technical support
More than 20 years of hands-on experience in PV & energy storage
Net discount conditions for registered partners
Professional access
  • Generic
  • Apple Pay
  • Bancontact
  • Google Pay
  • iDEAL Wero
  • Klarna
  • Maestro
  • Mastercard
  • MobilePay
  • PayPal
  • Visa

The Solis FlexHome-BAT5kWh-H is a modular 5 kWh LiFePO4 high-voltage home battery module for the FlexHome energy storage system. With a cell capacity of 100 Ah, 100% DoD and an IP66 protection rating, this module forms the basis for scalable storage configurations from 15 kWh to 160 kWh in combination with the FlexHome BMS and compatible Solis hybrid inverters.

  • 5 kWh LiFePO4 home battery module: 100 Ah cell capacity, 100% DoD — nominal voltage 51.2V.
  • Scalable from 15 kWh to 160 kWh: Modular stacking per stack and parallel configurations.
  • ≥ 6,000 charge cycles: Certified LiFePO4 quality compliant with IEC 62619 and UN 38.3.
  • IP66 protection rating: Suitable for installation in technical rooms and sheltered outdoor locations.
  • Direct Solis integration: Communication via CAN/RS485 with compatible Solis hybrid inverters.

Suitable for

  • New FlexHome high-voltage home battery installations
  • Expansion of existing FlexHome configurations
  • Residential energy storage with scalable capacity from 15 kWh to 160 kWh
  • Installations in combination with compatible Solis hybrid inverters via CAN/RS485
  • Systems with future expansion requirements up to 160 kWh

Solis FlexHome-BAT5kWh-H — specifications and benefits

  • Modular expansion: By stacking multiple modules, system capacity of 15 kWh to 40 kWh per stack and up to 160 kWh in parallel configurations is achievable.
  • Increased self-consumption: Integration with Solis hybrid inverters increases self-consumption to approximately 70%, resulting in lower energy costs and an improved LCOE.
  • Safe cell chemistry: Thermally stable LiFePO4 cells — non-toxic, non-flammable, fully compliant with IEC 62619 and VDE 2510-50.
  • Mandatory BMS: The FlexHome-CB50A-H BMS handles communication, protection and control of all battery modules — mandatory for correct system operation.
Property Value
Brand & model SolisStorage FlexHome-BAT5kWh-H
MPN FlexHome-BAT5kWh-H
Type High-voltage home battery module
Nominal capacity 5 kWh
Cell capacity 100 Ah
Battery type LiFePO4
Nominal voltage 51.2V
Operating voltage 44.8V – 57.6V
Recommended charge/discharge current 50A
Max. discharge current 50A
Depth of discharge (DoD) 100%
Cycle life ≥ 6,000 cycles
Protection rating IP66
Dimensions (W × D × H) 800 × 285 × 480 mm
Weight 50 kg
Certifications IEC 62619, IEC 63056, ISO13849, VDE 2510-50, UN 38.3, IEC 61000-6-1/2/3/4, IEC 60730-1, IEC 60529

Note: The official datasheet is always leading for the correct technical specifications.

Important, correct FlexHome HV configuration required: This battery module must be used exclusively within a correct FlexHome HV configuration with the FlexHome-CB50A-H BMS. Incorrect installation or configuration may result in system failure, performance loss or permanent damage. Installation must be carried out exclusively by certified electrical installers.
Download Datasheet Download Manual
What is included in the Solis FlexHome-BAT5kWh-H package?
Component Quantity
Battery module FlexHome-BAT5kWh-H 1
Installation screws 2
Packing list 1
How is the capacity of the FlexHome system expanded?

By stacking multiple FlexHome-BAT5kWh-H modules, a system capacity of 15 kWh to 40 kWh per stack is achievable. Via parallel configurations, a total system capacity of up to 160 kWh can be realised. Each module delivers 5 kWh nominal at 100% DoD. Please refer to the manual for the maximum stacking configuration and wiring requirements.

Which BMS is required for the FlexHome-BAT5kWh-H?

The FlexHome-CB50A-H BMS is mandatory for safe and correct system operation. It handles cell balancing, temperature protection, communication via CAN/RS485 and control of all battery modules. The system must not be operated without this BMS — incorrect configuration may result in system failure or permanent damage.

Which Solis inverters are compatible with the FlexHome-BAT5kWh-H?

The FlexHome-BAT5kWh-H is designed for use with compatible Solis hybrid inverters via CAN or RS485 communication. Compatibility depends on the inverter model and firmware version. Always refer to the most current compatibility list in the datasheet or manual before installation.
