Solis FlexHome-LV 5kWh battery module
The Solis FlexHome-BAT5kWh-L is a modular 5 kWh LiFePO4 low-voltage home battery module for the FlexHome energy storage system. With a cell capacity of 100 Ah, 100% DoD and an IP66 protection rating, this module forms the basis for scalable storage configurations from 5 kWh to 40 kWh per stack in combination with the FlexHome-CB210A-L BMS and compatible Solis low-voltage hybrid inverters.
- 5 kWh LiFePO4 home battery module: 100 Ah cell capacity, 100% DoD — operating voltage 44.8V – 57.6V.
- Scalable from 5 kWh to 40 kWh per stack: Modular stacking and parallel configurations for higher capacities.
- > 6,000 charge cycles / 10 years: Certified LiFePO4 quality compliant with IEC 62619 and UN 38.3.
- IP66 protection rating: Suitable for installation in technical rooms and sheltered outdoor locations.
- Direct Solis integration: Communication via CAN/RS485 with compatible Solis low-voltage hybrid inverters.
Suitable for
- New FlexHome low-voltage home battery installations
- Expansion of existing FlexHome-L configurations
- Residential energy storage with scalable capacity from 5 kWh to 40 kWh per stack
- Installations in combination with the FlexHome-CB210A-L BMS and compatible Solis low-voltage hybrid inverters
- Systems with future expansion requirements via parallel configurations
Solis FlexHome-BAT5kWh-L — specifications and benefits
- Modular expansion: By stacking multiple modules, system capacity of 5 kWh to 40 kWh per stack is achievable — expandable via parallel connection for higher total capacities.
- Increased self-consumption: Integration with Solis low-voltage hybrid inverters supports optimised energy management and significantly increases self-consumption to reduce LCOE.
- Safe cell chemistry: Thermally stable LiFePO4 cells — non-toxic, non-flammable, fully compliant with IEC 62619 and VDE 2510-50.
- Mandatory BMS: The FlexHome-CB210A-L BMS handles system protection, communication and control of all battery modules — mandatory for correct system operation.
| Property | Value |
|---|---|
| Brand & model | SolisStorage FlexHome-BAT5kWh-L |
| MPN | FlexHome-BAT5kWh-L |
| Type | Low-voltage battery module |
| Nominal capacity | 5 kWh |
| Cell capacity | 100 Ah |
| Battery type | LiFePO4 |
| Operating voltage | 44.8V – 57.6V |
| Recommended charge/discharge current | 50A |
| Max. charge current | 50A |
| Max. discharge current | 100A |
| Depth of discharge (DoD) | 100% |
| Cycle life | > 6,000 cycles / 10 years |
| Protection rating | IP66 |
| Dimensions (W × D × H) | 800 × 285 × 480 mm |
| Weight | 50 kg |
| Certifications | IEC 62619, IEC 63056, VDE 2510-50, UN 38.3, IEC 60529, IEC 60730-1, IEC 61000-6-1/2/3/4 |
Note: The official datasheet is always leading for the correct technical specifications.
What is included in the Solis FlexHome-BAT5kWh-L package?
| Component | Quantity |
|---|---|
| FlexHome-BAT5kWh-L battery module | 1 |
| Installation screws | 2 |
| Packing list | 1 |
How is the capacity of the FlexHome-L system expanded?
Capacity is expanded by stacking multiple FlexHome-BAT5kWh-L modules within one system, enabling configurations from 5 kWh to 40 kWh per stack. Higher total capacities are achievable via parallel systems. Each module delivers 5 kWh nominal at 100% DoD. Please refer to the manual for the maximum stacking configuration and wiring requirements.
Which BMS is required for the FlexHome-BAT5kWh-L?
The FlexHome-CB210A-L BMS is mandatory for safe and correct system operation. It handles cell balancing, temperature protection, system protection and communication via CAN/RS485 with compatible Solis low-voltage hybrid inverters. The system must not be operated without this BMS — incorrect configuration may result in system failure or permanent damage.
How does the FlexHome-BAT5kWh-L support Time-of-Use optimisation?
As time-of-use energy pricing becomes more widespread across Europe, accurate real-time storage control is increasingly important for financial optimisation. The FlexHome-BAT5kWh-L enables you to store solar energy generated during the day and use it in the evening or at night — reducing low-value grid exports and maximising self-consumption at the full retail electricity price. The actual financial benefit depends on your consumption profile, PV yield, energy contract and applicable grid tariffs. With a lifespan of > 6,000 cycles, a scalable system from 5 kWh to 40 kWh per stack and IP66 protection, the FlexHome-BAT5kWh-L is built for long-term returns.
