Aiko Neostar 3P54 AIKO-A495-MCE54Mw 495Wp Black Frame
Couldn't load pickup availability
The Aiko Neostar 3P54 AIKO-A495-MCE54Mw is a Black Frame Mono-Glass solar panel that delivers 495 Wp of nominal output with a module efficiency of 24.8% — placing it among the most efficient residential solar panels available today. Powered by the revolutionary ABC (All Back Contact) N-Type technology, front-side shading losses are eliminated entirely. Designed for installers and end users who demand maximum yield per m² combined with a clean, professional appearance.
- ABC N-Type Technology: Full rear-contact design delivering 24.8% module efficiency — no visible contact lines on the cells.
- Mono-Glass Construction: 3.2mm tempered glass on the front with a high weather-resistant backsheet for optimal protection at reduced weight.
- Low Degradation: Only 1% loss in the first year and ≤0.35% annually through year 30.
- Temperature Management: Optimal performance in heat with a temperature coefficient of -0.26%/°C.
- Black Frame Aesthetics: Black anodised aluminium frame for a professional and understated appearance on any roof.
Maximum Energy Yield with Aiko ABC Technology
The Aiko Neostar 3P54 series optimises the Levelized Cost of Energy (LCOE) by eliminating front-side shading losses entirely. With 108 cells (6×18) and a maximum system voltage of 1500V DC, this panel is fully suited for large-scale residential and light commercial installations. Combined with a hybrid inverter from Solis or GoodWe, this panel forms the foundation of a highly efficient energy ecosystem — with self-consumption potentially reaching approx. 70% thanks to stable output under diffuse light conditions.
With 495 Wp per panel and a cell efficiency exceeding 25.0%, the Neostar 3P54 delivers more yield per m² of roof space than conventional PERC or TOPCon panels. At just 20.6 kg — significantly lighter than comparable glass-glass panels — installation is easier and the load on the roof structure is considerably reduced.
| Feature | Value |
|---|---|
| Brand & Model | Aiko Neostar 3P54 (AIKO-A495-MCE54Mw) |
| Nominal Output (Pmax) | 495 Wp |
| Module Efficiency | 24.8% |
| Power Tolerance | 0 ~ +3% |
| Temperature Coefficient (Pmax) | -0.26%/°C |
| Dimensions | 1762 × 1134 × 30 mm |
| Weight | 20.6 kg (±3%) |
| Construction | Mono-Glass, 3.2mm tempered glass (front) + backsheet |
| Number of Cells | 108 (6×18) N-Type ABC |
| Connector | Original MC4 |
| Maximum System Voltage | 1500V DC |
| Certifications | IP68, Class II, IEC Class C Fire Rating |
| Product Warranty | 15 years (extendable to 25 years*) |
| Power Warranty | 30 years (≥88.85% residual output) |
Note: The official datasheet contains full electrical and mechanical specifications.
What is included in the Aiko Neostar 3P54 package?
| Solar Panel | Aiko AIKO-A495-MCE54Mw |
| Cables | 1200mm 4mm² (pre-assembled) |
| Connector | Original MC4 |
| Frame | Black anodised aluminium |
Which inverters and systems are compatible with the Aiko Neostar 3P54?
What is the difference between the Neostar 3P54 (mono-glass) and the Neostar Pro (glass-glass)?
The Neostar 3P54 uses a mono-glass construction with 3.2mm tempered glass on the front and a high weather-resistant backsheet on the rear. This results in a significantly lower weight of 20.6 kg compared to 24.5 kg for glass-glass variants — a key advantage for roof structures with limited load capacity. The glass-glass variant offers higher mechanical protection and Fire Safety Class A; the 3P54 is certified to Fire Safety Class C in accordance with IEC standards.
How does the Aiko Neostar 3P54 perform in cloudy conditions and diffuse light?
Thanks to the N-Type ABC cell structure, the Neostar 3P54 delivers superior performance under diffuse light conditions — critical for markets with variable weather such as the UK, Benelux, and Northern Europe. The absence of front-side contact lines completely eliminates cell-level shading losses, resulting in an earlier production start and a longer generation period throughout the day. This significantly increases direct self-consumption, particularly relevant under Time-of-Use tariffs and dynamic energy contracts.
What warranties apply to the Aiko Neostar 3P54?
The Aiko Neostar 3P54 comes with a standard product warranty of 15 years, extendable to 25 years*, and a linear 30-year power output warranty. After 30 years, a minimum residual output of 88.85% is guaranteed. Annual degradation is capped at 0.35% from year 2 onwards — among the lowest in the industry. The warranty is backed by Munich RE® as an independent guarantee partner.
Explore more products in the Aiko Solar collection.
