Anker SOLIX Power Dock (X1 Gateway & EV Controller)

€429,55 incl. VAT
Shipping calculated at checkout.

The Anker SOLIX Power Dock is the intelligent nerve center of the SOLIX X1 system. This advanced gateway streamlines energy distribution between your solar panels, home battery, grid, and electric vehicle. Powered by PluginPower™ technology and AI-driven energy management, the Power Dock eliminates energy waste and maximizes independence. Featuring a robust IP54 housing, it is designed for installation in garages or protected outdoor areas.

  • EV Charging Ready: Dedicated ports for 7.4kW (single-phase) and 11kW (three-phase) EV chargers.
  • Warranty & Lifecycle: 10-year manufacturer warranty and 15-year expected lifecycle.
  • Robust Design: IP54 rated (Protected against dust and splashing water).
  • Smart Management: Seamless integration with the Anker App for real-time monitoring.
Installation Warning: Never connect a single-phase and three-phase Anker SOLIX Smart EV Charger to the Power Dock simultaneously. The system requires proper wiring (min 6mm², recommended 10mm²) for safe operation.

Technical Specifications

The Power Dock acts as a central hub, managing up to 14.4 kW PV-Input and 4.8 kW AC-Output. Its modular design makes future storage capacity expansion (up to 64.5 kWh) simple.

Model Anker SOLIX Power Dock (AE100)
Dimensions 429 × 174.5 × 345 mm
Weight (Net) 11 kg
IP Rating IP54
EV Output Power 7.4kW (1-Phase) / 11kW (3-Phase)
AC Output Voltage 230VAC (L+N+PE) / 400VAC (L1+L2+L3+N+PE)

Frequently Asked Questions (FAQ)

What is inside the box?
  • 1x Anker SOLIX Power Dock
  • 1x Wall Bracket
  • 3x Expansion Screws (M5 x 60mm)
  • 1x 10-Pin Terminal Block Connector
  • Documentation (User Manual & Warranty Card)
Where should I install the Power Dock?
It is recommended to place the Power Dock inside a garage. For comfortable two-handed operation (e.g., opening the cover), install the dock at chest level. The operating temperature range is -20°C to 55°C.
Is the system compatible with my EV charger?
The Power Dock is specifically designed to work with the Anker SOLIX Smart EV Charger. It features dedicated ports for single-phase and three-phase charging. Note: Use cables with a cross-section of 10mm² for optimal performance and future-proofing.
How does the warranty work?
Anker provides a leading 10-year limited warranty for the Power Dock when purchased through authorized resellers. Register your product via the Anker App to activate priority customer service.

Want to learn more about the complete system?

View Anker SOLIX X1 Collection (EN)
Download Datasheet Download Manual
