Anker Solix X1-H8K-T 3-Phase Hybrid Inverter
Couldn't load pickup availability
The Anker Solix X1-H8K-T is the ideal 3-phase hybrid inverter for households seeking maximum energy independence without compromising on design. Delivering 8kW of continuous power and supporting up to 200% PV oversizing (16kW input), it ensures maximum yields even on cloudy days. The system maintains a signature ultra-slim profile of just 150 mm depth.
- High Performance: 8 kW AC output and support for up to 16 kW PV input (200% oversizing).
- Ultra-Slim Design: Only 15 cm deep, allowing for an aesthetic and space-saving integration.
- UPS-Level Backup: Switches to emergency power in less than 10ms during a grid outage.
- Extreme Resilience: IP66-certified and C5 corrosion protection for reliable operation from -25°C to 60°C.
8kW Hybrid Efficiency: The Perfect Balance
The X1-H8K-T is more than just an inverter; it acts as an intelligent energy management system. Thanks to AI-driven software and SG-Ready functionality, the system optimizes your self-consumption automatically. Whether installed in a garage or on an exterior wall, its whisper-quiet operation and robust design guarantee years of worry-free use.
| Property | Value |
|---|---|
| Model | Anker Solix X1-H8K-T (3-Phase) |
| Nominal AC Power | 8,000 W (8 kW) |
| PV Input Range | 150V – 1000V (Max. 16 kW PV input) |
| Maximum Efficiency | 98.0% (97.4% EU) |
| System Depth | Only 150 mm (Ultra-slim) |
| Protection Rating | IP66 (Dust and Waterproof) |
| Warranty | 10-Year Manufacturer Warranty |
| Weight | 30 kg (Power Module) |
What is included in the package?
The Anker Solix X1-H8K-T is delivered as a complete, ready-to-install package:
- 1x Power Module (X1-H8K-T Inverter)
- 1x 3-Phase Smart Meter (DTSU666 including CT clamps)
- 1x WLAN/Ethernet Dongle for app monitoring
- Wall mounting bracket, floor mounting set, and cable covers
- Necessary AC/DC connectors and manuals
Which batteries and panels are compatible with this system?
This inverter works exclusively with original Anker Solix X1 Battery Modules (5kWh LFP) for maximum efficiency. Regarding solar panels, the system is universally compatible with Tier-1 brands such as Aiko, Jinko Solar, DMEGC, Hyundai, Trina Solar, Longi, and JaSolar.
Is the system expandable later on?
Certainly. Thanks to the modular design, you can scale flexibly. Start with a single 5kWh module and expand up to 30kWh (6 modules) on this single 8kW inverter. For larger projects, up to 6 full X1 systems can be connected in parallel.
How safe and robust is the installation?
With an IP66 rating, the system is completely dust and waterproof. Internally, the inverter features active protection against arc faults (AFCI) and intelligent temperature management. The C5 corrosion protection makes it suitable even for challenging installation environments.
Is this inverter suitable for dynamic energy tariffs?
Yes, it is a core feature. The software can automatically charge the battery when electricity prices (e.g., Tibber or ANWB) are low or negative, and discharge during expensive peak hours. This maximizes your ROI and significantly reduces grid dependency costs.
View the full collection: Anker Solix X1 System.
